Low Cost Wooden Duplicator
How to make it, how to use it
Construction details for a stencil duplicator that can be built using simple woodworking tools, and is easy to use and maintain. Includes templates for use in construction.
Published: 1984
Pages: 20
eBook: 9781780442679
Paperback: 9780946688418
Construction details for a stencil duplicator that can be built using simple woodworking tools, and is easy to use and maintain. Includes templates for use in construction.
| 9781780442679.000 | 1 | ||
|---|---|---|---|
| 9781780442679.001 | 5 | ||
| General Description | 6 | ||
| Parts and Materials List | 7 | ||
| How to Build it | 8 | ||
| How to use the Templates | 10 | ||
| Making the Stencil Drum | 11 | ||
| Making the Side Panels and Base | 14 | ||
| Deflector Plate | 23 | ||
| Making the Pressure and Inking Rollers | 24 | ||
| Bearings | 25 | ||
| Making the Cover Panels | 26 | ||
| How to use the Duplicator | 27 | ||
| The Stencil | 29 | ||
| Taking the Copies | 30 | ||
| Caution | 31 |
